MULTISPAN MFM-13-M1-E3-01-32

Name: MULTISPAN MFM-13-M1-E3-01-32
Brand: ELITE INDUSTRIAL ENGINEERS
Price: 2310 INR
Availability: InStock

Price 2310 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MULTISPAN MFM-13-M1-E3-01-32 Specification

Automation Grade
Automatic

IP Rating
IP54

Weight
Approx 250 grams

Application
Three Phase Panel Meter, Energy Management

Frequency
45-65 Hz

Control Type
Digital

Phase
Three Phase

Mounting Type
Panel Mount

Processor Type
Microcontroller Based

Screen Size
0.56 inch LED Display

Features
Multi-Function Meter, Programmable CT/PT, True RMS Measurement, Backlit Display, Sealable Terminal Cover

Connectivity Type
RS485 (MODBUS RTU)

Material
Plastic Body, ABS & Polycarbonate Front Plate

Power
Auxiliary Power Supply: 80-270V AC/DC

Temperature
Operating Temp: 0-55°C

Voltage
Input Voltage: 11-300V AC (Phase to Neutral), 19-519V AC (Phase to Phase)

Relative Humidity
Less than 95% non-condensing

Type
Multi-Function Panel Meter

Compliance
IS/IEC Standard

Display Type
3 Row 4 Digit 7-Segment LED Display

Current Input
1A / 5A (Programmable)

Accuracy
Class 0.5/1.0

Model
MFM-13-M1-E3-01-32

Dimensions
96 x 96 x 52 mm

Display Parameters
V, I, Hz, kW, kVA, kVAR, PF, kWh, kVAh, kVARh, MAX Demand

MULTISPAN MFM-13-M1-E3-01-32 About

MULTISPAN MFM-13-M1-E3-01-32

AUX VOLTAGE :- 100 TO 270V AC / DC

OUTPUT :- PULSE OUTPUT

ACTION :- N / A

SENSOR :- CT INPUT :3

RANGE :- PRIMARY VOLTAGE : 100V TO 520KV AC

SECONDARY VOLTAGE : 100V TO 520V AC

3 Line Display 100V to 520V AC (L-N), 100V to 520KV AC PT Primary + 5A CT Secondary 100-270V AC OR 20-60V DC Factory Set

Comprehensive Parameter Monitoring

This multi-function panel meter enables real-time monitoring of a wide array of electrical parameters-including phase-to-neutral and phase-to-phase voltages, current, power, and energy metrics. Its 3-row display ensures you can track several parameters simultaneously, supporting efficient analysis and management of your electrical systems.

Versatile and Reliable Design

Built with a durable plastic enclosure and a polycarbonate front for increased resilience, the MFM-13-M1-E3-01-32 offers reliable operation with IP54 protection and high accuracy (Class 0.5/1.0). Suitable for environments with relative humidity up to 95%, it operates effectively within the temperature range of 0-55C, fitting seamlessly into most panel mounting applications.

Advanced Connectivity and Automation

Equipped with RS485 (MODBUS RTU) connectivity, this meter can be integrated into automation systems for remote monitoring and data acquisition. Its programmable current inputs and CT/PT ratios enhance versatility for various industrial and commercial applications, while features like a sealable terminal cover ensure operational safety and compliance.

FAQ's of MULTISPAN MFM-13-M1-E3-01-32:

Q: How do I program the CT/PT ratios on the MFM-13-M1-E3-01-32 panel meter?

A: Programming the CT and PT ratios can be done through the front panel keys following the meter's user manual. Navigate to the setup mode and input the required ratios based on your installation to ensure accurate measurement.

Q: What electrical parameters can this meter display in real time?

A: The MFM-13-M1-E3-01-32 displays voltage (V), current (I), frequency (Hz), active power (kW), apparent power (kVA), reactive power (kVAR), power factor (PF), active energy (kWh), apparent energy (kVAh), reactive energy (kVARh), and maximum demand values.

Q: When is this panel meter typically used?

A: This multi-function panel meter is commonly used in energy management systems, industrial automation controls, and three-phase electrical panels for monitoring and analyzing electrical performance.

Q: Where should the MFM-13-M1-E3-01-32 be installed for optimal operation?

A: It is designed for panel mounting in switchboards or distribution panels. The recommended installation location is an indoor, ventilated panel where it is protected from excessive moisture and dust, ensuring compliance with its IP54 rating and operational reliability.

Q: What benefits does the RS485 (MODBUS RTU) connectivity provide?

A: The RS485 (MODBUS RTU) connectivity allows seamless integration with building management or automation systems, enabling remote data logging, energy analysis, and parameter monitoring from centralized locations.

Q: How does this meter handle high humidity or temperature conditions?

A: The device operates effectively in environments with relative humidity less than 95% (non-condensing) and within a temperature range of 0-55C, making it suitable for most industrial and commercial settings.
