INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP

Send Inquiry

Request To Call Back

INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP

Name: INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP
Brand: ELITE INDUSTRIAL ENGINEERS
Price: 12000 INR
Availability: InStock

Price 12000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP Specification

Features
MPPT, Built-in Soft Start, Dry Run Protection, Overload & Short Circuit Protection

Control Type
V/F Control, Sensorless Vector Control

Processor Type
Digital Signal Processor (DSP)

Speed Range
0.50 to 400 Hz

Load Capacity
Suitable for 2.2KW / 3HP Motor

Drive Type
Variable Frequency Drive (VFD)

IP Rating
IP20

Sensor Type
Support for External/Optional Pressure and Flow Sensors

Weight
Approx. 2.1 kg

Frequency
50/60 Hz

Connectivity Type
Modbus, RS485

Screen Size
4-Digit LED Keypad Display

Remote Control
Yes

Mounting Type
Panel Mount

Cable Length
Customizable / As per application

Automation Grade
Automatic

Phase
Single Phase Input / Three Phase Output

Application
Solar Water Pump System, Solar Drive Automation

Material
ABS Plastic & Metal

Power
2.2KW / 3HP

Temperature
-10°C to 50°C (Operating Temperature)

Voltage
220V AC (Input Voltage)

Display Type
LED Digital

Pump Type
Centrifugal and Submersible Pumps

Enclosure
IP20 Standard Enclosure

Overvoltage Protection
Yes

Motor Compatibility
Induction AC Motors (Three-phase)

Humidity
Less than 95% RH, non-condensing

Compliance/Certifications
CE Certified

Rated Current
11A

Altitude Tolerance
Below 1000m without derating

Cooling Method
Forced Air Cooling

Control Panel
Keypad and Remote Control through RS485

Model Number
GD20-2R2G-SS2-F1

Setting Method
Panel Keypad and Communication Port

Undervoltage Protection
Yes

About INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP

Unlock rarefied levels of control and efficiency for your solar water pump systems with the INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP-now at a reduced price! As a top-tier solution, this excellent variable frequency drive boasts extraordinary features such as overvoltage and undervoltage protection, forced air cooling, and robust IP20 enclosure. Easily redeem maximum productivity with dual operation modes, seamless Modbus/RS485 connectivity, and advanced DSP technology. Enjoy excellent application performance for induction AC motors, centrifugal, and submersible pumps. CE certified, suitable for distributors, manufacturers, and suppliers across India.

Durable Material and Versatile Use

Crafted from premium ABS plastic and metal, the INVT VFD SOLAR GD20-2R2G-SS2-F1 offers outstanding durability and resilience. This remarkable drive is not only excellent for solar water pump systems but is also perfectly suited for solar drive automation in agricultural and industrial zones. Its versatile surface application allows easy integration into panel mounting setups, adapting to various operational environments with consistent reliability and protection.

Flexible Delivery, Market Reach, and Payment Options

Products are safely delivered via FOB at major ports and promptly handed over to clients across India's main domestic markets. Buyers can select from multiple payment methods to streamline transactions and avoid unnecessary charges. Our efficient delivery process ensures that orders are executed smoothly, with dedicated support for distributors, suppliers, and traders to facilitate a hassle-free acquisition experience.

FAQ's of INVT VFD SOLAR GD20-2R2G-SS2-F1 2.2KW/3HP:

Q: How can I redeem the maximum benefits of the INVT VFD SOLAR GD20-2R2G-SS2-F1 in solar water pump applications?

A: You can achieve optimal results by installing the VFD in accordance with the panel mounting guidelines, utilizing its MPPT and protection features, and by configuring it via the user-friendly panel keypad or remote RS485 communication.

Q: What types of motors and pumps are compatible with this VFD model?

A: The GD20-2R2G-SS2-F1 is compatible with three-phase induction AC motors and is specifically designed for use with centrifugal and submersible pumps, making it ideal for solar-driven systems.

Q: When is it necessary to use the external sensor option for this drive?

A: External pressure and flow sensors are recommended in applications where precise monitoring and smart automation of water delivery are required, such as in fluctuating solar or environmental conditions.

Q: Where can I install the INVT VFD SOLAR GD20-2R2G-SS2-F1?

A: This VFD is suitable for installation in control panels within agricultural fields, solar pump stations, and industrial water automation systems. The unit must be mounted in locations that meet its IP20 enclosure and environmental requirements.

Q: What process should I follow for remote control using the RS485 and Modbus interface?

A: First, connect the VFD to the RS485 network. Next, configure the Modbus communication parameters in the settings menu. This enables real-time remote control, monitoring, and diagnostics through compatible communication systems.

Q: What are the main advantages of using the INVT VFD for solar water pump systems?

A: Benefits include energy savings from MPPT optimization, comprehensive protection mechanisms (such as soft start and dry run prevention), reliable automation, compatibility with diverse pump types, and excellent adaptability to harsh operating conditions.
