INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4

Name: INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4
Brand: ELITE INDUSTRIAL ENGINEERS
Price: 15900 INR
Availability: InStock

Price 15900 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4 Specification

Load Capacity
Heavy/General Duty

Application
Industrial, Pumps, Fans, Conveyors, HVAC

Automation Grade
Automatic

IP Rating
IP20

Mounting Type
Panel Mount

Control Type
Vector Control, V/F Control

Processor Type
Digital Signal Processor (DSP)

Remote Control
Yes

Weight
Approx. 4.5 kg

Sensor Type
Optional External Sensors

Drive Type
Variable Frequency Drive (VFD)

Speed Range
0.5 to 400 Hz

Screen Size
LCD Keypad Display

Phase
Three Phase

Frequency
50/60 Hz

Cable Length
User Defined

Connectivity Type
RS485, Modbus

Features
Overload Protection, Fault Diagnosis, Multiple I/O, High Torque at Low Speed, Energy-saving Operation

Material
Plastic and Metal Components

Power
7.5 HP (5.5 kW)

Temperature
-10C to +50C

Voltage
380-480V AC

Output Current
13A

Braking Unit
Built-in

Humidity
Less than 95% RH (non-condensing)

EMC Compliance
EN61800-3

Enclosure Type
Compact, Wall Mountable

Ambient Altitude
1000 meters (derate above 1000m)

Model Number
GD200A-5R5G/7R5P-4

Input Voltage Range
3 Phase 380V~480V 15%

Cooling Method
Forced Air Cooling

Protection Functions
Overcurrent, Overvoltage, Undervoltage, Overheat, Phase Loss, Short Circuit

Insulation Class
Class F

Control Method
Open Loop Vector, Closed Loop Vector (optional), V/F control

Programming Method
Keypad, PC Tool

Communication Protocols
Modbus RTU

Life Expectancy
Designed for >10 years Operation

INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4 About

The INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4 is a cost-effective, top-rated variable frequency drive renowned for its superior performance and extraordinary reliability. With robust output current (13A) and advanced protection functions like overcurrent, overvoltage, and phase loss, this model guarantees safe operations. Its compact enclosure, built-in braking unit, and advanced vector control make installation easy and operation seamless. Supported by cutting-edge DSP technology, this automatic VFD ensures energy-saving, high-torque management for diverse industrial, pump, fan, conveyor, and HVAC applications. Enjoy a deal backed by trusted suppliers, manufacturers, and traders across India.

Application Versatility & Key Features

Ideal for industrial automation, pumps, fans, conveyors, and HVAC systems, the INVT VFD GD200A 7.5HP model offers heavy and general duty load capacities. Its compact, wall-mountable design and panel mount compatibility make it suitable for different installation environments. Superior features such as overload protection, fault diagnosis, and multi-I/O connectivity support optimized performance. The unit ensures high torque even at low speeds, with energy-saving operation and user-defined cable lengths enhancing adaptability to various sites of application.

Sample Policy and Delivery Logistics

INVT provides a straightforward sample policy, so clients can request device samples before confirming bulk expenditure. With competitive supply ability and efficient logistics, timely delivery is assured. Quotation requests are processed rapidly, allowing buyers to access top deals. Delivery times depend on order volume and destination, but suppliers across India maintain prompt shipping and comprehensive client support, contributing to a seamless acquisition experience for manufacturers, distributors, and traders.

FAQ's of INVT VFD GD200A 7.5HP 3PHASE GD200A-5R5G/7R5P-4:

Q: How can I install the INVT VFD GD200A 7.5HP in my industrial setup?

A: This VFD features a compact, panel-mountable design suitable for wall installation. Detailed installation instructions are provided in the manual, ensuring easy integration into existing automation processes.

Q: What types of protection does the GD200A-5R5G/7R5P-4 offer during operation?

A: The device includes safety mechanisms against overcurrent, overvoltage, undervoltage, phase loss, overheat, and short circuit, ensuring the highest level of operational reliability and equipment longevity.

Q: Where is the INVT VFD GD200A most commonly used?

A: This model is ideally suited for industrial machinery, pumps, fans, conveyors, and HVAC systems, delivering extraordinary torque and efficiency across multiple heavy-duty applications.

Q: What is the benefit of choosing this VFD in terms of energy conservation?

A: Utilizing both vector and V/F control methods, the drive optimizes motor speed according to load requirements, significantly reducing electricity consumption and operational expenditure.

Q: How are product samples and quotations managed for suppliers and distributors?

A: Interested buyers can request quotations and sample units through official distribution channels. The selection process is swift, supported by clear sample policies and competitive offers from Indian suppliers.

Q: What is the expected lifespan and reliability of the GD200A VFD?

A: Designed for more than 10 years of continuous operation, this drive offers reliable performance, EMC compliance, and superior fault diagnosis capabilities to ensure consistent productivity in demanding environments.
