MULTISPAN MPD-152-A2-00

Name: MULTISPAN MPD-152-A2-00
Brand: ELITE INDUSTRIAL ENGINEERS
Price: 1496.2 INR
Availability: InStock

Price 1496.2 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MULTISPAN MPD-152-A2-00 Specification

Screen Size
0.56 (LED Display)

Mounting Type
Panel Mount

Cable Length
As per panel wiring

Control Type
Digital

Remote Control
Yes

Load Capacity
Upto 10A Input (Current Measuring)

Frequency
50/60 Hz

IP Rating
IP20 (Front Panel)

Processor Type
Microcontroller-Based

Application
Panel Mount, Electrical Parameter Monitoring

Weight
Approx. 200g

Features
Bright LED Display, Universal Supply, Compact Size

Connectivity Type
Panel mount, Terminal

Phase
1 Phase / 2 Wire

Automation Grade
Automatic

Sensor Type
Built-in CT or External CT Supported

Material
Plastic (Front), Metal (Enclosure)

Power
230V AC, 50Hz, <3W

Temperature
0 to 50°C (Operating)

Voltage
85-270V AC/DC Universal Supply

Enclosure
ABS Plastic (Fire Retardant)

Model
MPD-152-A2-00

Display
3 Digit, 7 Segment Red LED

Measuring Parameters
Voltage, Current, Frequency, Power Factor, Active/Reactive Power & Energy

Humidity
<95% RH Non-condensing

Accuracy
±0.5% of FSD

Cut-out Size
92mm x 92mm

Input Range
Voltage: 0-500V, Current: 0-10A (via CT), Frequency: 45-65Hz

MULTISPAN MPD-152-A2-00 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Days

MULTISPAN MPD-152-A2-00 About

MULTISPAN MPD-152-A2-00

AUX VOLTAGE :- 100 TO 270V AC

OUTPUT :- 1 RELAY

ACTION :- N / A

SENSOR :- CT INPUT : 3

RANGE :- CT PRIMARY : 5A TO 6000A , CT SECONDARY : 5A

30 to 300V AC (L-N), 50 to 520V AC (L-L) 1R 1 C/O 100 to 270V AC

Comprehensive Electrical Monitoring

The MPD-152-A2-00 enables precise real-time monitoring of vital electrical parameters, including voltage, current, frequency, power factor, active and reactive power, and energy. This broad spectrum of measurement makes it ideal for electrical panels in industrial and commercial setups.

Robust Design for Easy Integration

Encased in a sturdy, fire-retardant ABS plastic enclosure, this device is engineered for durability. Its panel mount design, compact cut-out size, and bright LED display facilitate seamless integration into new or existing switchboards or control cabinets.

Accurate & Automatic Operation

Built on a microcontroller platform, the MPD-152-A2-00 delivers 0.5% accuracy of full-scale reading. Its automation grade ensures plug-and-play installation without manual calibration, supporting operational efficiency across a wide voltage range and harsh environments.

FAQ's of MULTISPAN MPD-152-A2-00:

Q: How do I install the MULTISPAN MPD-152-A2-00 in my control panel?

A: The device is designed for panel mounting with a standard cut-out size of 92mm x 92mm. Simply connect the supply voltage to the terminals (85-270V AC/DC) and route input wires for voltage and current (using CT for current measurement). Secure the unit using the provided mounting hardware.

Q: What electrical parameters can this digital meter measure?

A: The MPD-152-A2-00 measures voltage, current (via built-in or external CT), frequency, power factor, active power, reactive power, and energy-all displayed on a 3-digit bright red LED for quick visibility.

Q: When should I use this meter in my application?

A: You should use this panel meter when you require accurate, real-time monitoring of single-phase electrical parameters for energy auditing, load monitoring, or power quality analysis in distribution panels or switchboards.

Q: Where is the ideal location for mounting this device?

A: The ideal location is within an indoor electrical panel or distribution box where you need localized display and access to electrical parameter readings. It is suitable for compact panels due to its small footprint and easy integration.

Q: What benefits does the MULTISPAN MPD-152-A2-00 offer over analog meters?

A: Compared to analog meters, this digital meter provides improved accuracy (0.5% of FSD), a clear and easily readable display, multiple parameter measurement in one device, universal power supply compatibility, and automatic operation with minimal maintenance.

Q: How does the meter ensure accuracy in diverse environments?

A: The unit is designed to operate with a high degree of accuracy (0.5% of FSD) between 0 to 50C and up to 95% relative humidity (non-condensing), making it dependable in various industrial and commercial environments.
