MULTISPAN FRT-22U-00

Price 625.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MULTISPAN FRT-22U-00 Specification

Connectivity Type
Panel Mount

Mounting Type
Panel Mounting

Application
Temperature Monitoring and Control

Screen Size
2 Digit Red LED Display

Weight
Approx. 250 g

Control Type
Digital

Load Capacity
10A, 230V AC (Resistive Load)

Frequency
50/60 Hz

IP Rating
IP20

Automation Grade
Automatic

Remote Control
Yes

Features
Digital Temperature Indicator and Controller

Phase
Single Phase

Sensor Type
PT-100 Sensor Compatible

Processor Type
Microcontroller Based

Cable Length
1.5 m (Sensor Cable)

Material
Plastic Body with Polycarbonate Front

Power
230 VAC, 50/60 Hz Supply

Temperature
-10°C to 55°C (Operating)

Voltage
230 V AC

Setpoint Range
0°C to 99°C

Relay Output Rating
10A, 230VAC resistive

Number of Outputs
2 Relay Outputs (NO + NC)

Display Type
2-Digit 7 Segment LED

Enclosure Type
Flameproof Polycarbonate

Control Action
ON/OFF Control

Cutout Size
66 mm x 66 mm

Alarm Function
Inbuilt Buzzer

MULTISPAN FRT-22U-00 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
5 Days

MULTISPAN FRT-22U-00 About

MULTISPAN FRT-22U-00

AUX VOLTAGE :- 12V TO 240V DC & 20V TO 240V AC

OUTPUT :- 2 RELAY

ACTION :- N / A

SENSOR :- N / A

RANGE :- 0.1 TO 10 SEC / MIN / HOUR

12 V DC to 240 V DC & 20 to 240 V AC, 50/60 Hz 2-Relay O/P, 1-C/O, 5A 230 VAC (Resistive Load) - 1st Relay for forward time & 2nd Relay for reverse time

Accurate and Reliable Temperature Control

The MULTISPAN FRT-22U-00 offers precise ON/OFF temperature control with a microcontroller-based system. Its 2-digit, 7-segment LED display ensures clear temperature readings, while the PT-100 sensor compatibility enhances measurement accuracy across a wide setpoint range. With built-in relay outputs, it provides reliable performance for managing and regulating temperatures in diverse industrial settings.

Rugged Flameproof Enclosure for Industrial Safety

Designed with a flameproof polycarbonate enclosure and a durable plastic body, this controller ensures safety during operation, even in harsh industrial environments. Its panel mount design, secure cutout size, and IP20 rating help protect the internal electronics, offering peace of mind and physical durability for continuous use.

User-Friendly and Automatic Operation

With an automatic control type and an inbuilt buzzer alarm, this digital controller simplifies temperature management. Its intuitive interface enables straightforward setting and monitoring, while the audible alarm promptly notifies users of any temperature deviations, enhancing operational efficiency and safeguarding equipment and processes.

FAQ's of MULTISPAN FRT-22U-00:

Q: How is the MULTISPAN FRT-22U-00 installed and connected?

A: The controller is designed for easy panel mounting using a 66 mm x 66 mm cutout. It requires a single-phase 230 VAC (50/60 Hz) power supply and should be connected to compatible PT-100 sensors for accurate temperature measurement. Relay outputs are accessible for controlling auxiliary devices, supporting both NO and NC connections.

Q: What applications benefit from using the MULTISPAN FRT-22U-00?

A: This digital temperature controller is ideal for use in industrial environments where reliable temperature monitoring and control are essential, such as manufacturing processes, laboratories, HVAC systems, and equipment protection. Its robust design and automatic operation enhance productivity and safety.

Q: When does the inbuilt buzzer alarm activate?

A: The inbuilt buzzer alarm is triggered whenever the measured temperature goes beyond the set limits defined by the user. This immediate alert helps operators respond promptly to temperature deviations and protect equipment or processes from potential damage.

Q: Where can this controller be mounted, and what are the mounting requirements?

A: The MULTISPAN FRT-22U-00 supports panel mounting and requires a cutout size of 66 mm x 66 mm. Its compact and flameproof design makes it suitable for installation in industrial control panels, machine enclosures, or operational monitoring boards.

Q: What sensor types are compatible with the MULTISPAN FRT-22U-00?

A: This controller is compatible with standard PT-100 temperature sensors, ensuring high-precision measurement and control within the 0C to 99C setpoint range.

Q: How does the ON/OFF control action benefit users?

A: The ON/OFF control action provides straightforward temperature regulation by activating the relay output once the setpoint is reached. This approach ensures precise thermal management and is particularly effective for applications requiring simple, reliable temperature control without complex tuning.

Q: What safety and protection features does the controller offer?

A: The flameproof polycarbonate enclosure minimises fire risks, while the IP20 rating offers basic protection against accidental contact. The audible buzzer alarm and automatic control further enhance operational safety and prevent equipment overheating or temperature-related failures.
