DELTA VFD MS300 VFD13AMS43ANSAA

Name: DELTA VFD MS300 VFD13AMS43ANSAA
Brand: ELITE INDUSTRIAL ENGINEERS
Price: 20748 INR
Availability: InStock

Price 20748 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DELTA VFD MS300 VFD13AMS43ANSAA Specification

Sensor Type
Sensorless Vector Control

Speed Range
0.1 ~ 599 Hz

Screen Size
Digital Keypad Included

Frequency
50/60Hz

Connectivity Type
RS-485 (MODBUS) Communication

Cable Length
User Defined

Application
Industrial Motor Control

Weight
2.7 kg

Mounting Type
Panel Mount

Automation Grade
Automatic

Drive Type
AC Motor Drive

IP Rating
IP20

Phase
Three Phase

Remote Control
Yes

Processor Type
32-bit DSP

Control Type
Vector Control, V/F Control

Features
Built-in EMC Filter, STO SIL2 Safety Function, Energy Saving, Compact Design

Load Capacity
1.5 kW

Material
Plastic, Metal

Power
13A

Temperature
-10°C to +50°C

Voltage
415V AC

Cooling Method
Fan Cooled

EMI Filter
Built-in

Enclosure Type
Open Frame

Communication Ports
Optional (CANopen, Profibus, Ethernet)

Model
VFD13AMS43ANSAA

Display Type
Digital LED

Protection Features
Overcurrent, Overvoltage, Overtemperature, Short Circuit

Input Voltage Tolerance
10%

Series
MS300

Overload Capacity
150% for 60 Sec, 200% for 3 Sec

About DELTA VFD MS300 VFD13AMS43ANSAA

DELTA VFD MS300 VFD13AMS43ANSAA

INPUT :- NORMAL DUTY : 3PH 380-480V ,17.3A , 50/60HZ

HEAVY DUTY : 3PH 380-480V , 14.3A , 50/60HZ

OUTPUT : POWER 7.5HP ND (HD)

NORMAL DUTY : 3PH 0-460V ,15.7A , 12.0KVA , 5.5KW

HEAVY DUTY : 3PH 0-460V , 13A , 9.9KVA , 5.5KW

FREQUENCY RANGE :- 0-599HZ

7.5 HP - 460 V

Advanced Performance for Industrial Motor Control

Experience smooth and precise motor operation with the MS300 series 32-bit DSP and advanced vector control. Even under fluctuating load conditions, enjoy high torque and stability thanks to a 150% overload allowance for 60 seconds and 200% for brief surges. The drive is engineered for durability in demanding environments, with comprehensive protection against overcurrent, overvoltage, overtemperature, and short circuit.

Efficient Installation and Maintenance

The VFD13AMS43ANSAA supports quick installation with its compact panel-mountable enclosure and open-frame design. Built-in LED display, remote control capability, and optional communication modules like CANopen and Profibus simplify both monitoring and integration. Maintenance is facilitated by the built-in fan cooling and EMC filter, reducing downtime and ensuring smooth, long-term operation.

Flexible Connectivity and Safety Features

Seamlessly connect with automation systems via RS-485 MODBUS, and enhance operational safety with the integrated STO SIL2 function. The VFDs built-in EMI filter ensures electromagnetic compatibility, making it suitable for sensitive industrial environments. With remote control support and user-defined cable lengths, customization for specific industrial setups is straightforward and efficient.

FAQs of DELTA VFD MS300 VFD13AMS43ANSAA:

Q: How do I configure and operate the DELTA VFD MS300 VFD13AMS43ANSAA for my industrial motor?

A: The VFD13AMS43ANSAA is easily configured using its digital LED keypad. Parameters for motor control, such as speed and acceleration, can be set directly on the keypad or via RS-485 (MODBUS) communication. Consult the user manual for step-by-step setup, and ensure wiring and mounting align with recommended panel installations.

Q: What protection features are included in this model for safe industrial usage?

A: This VFD offers comprehensive protection, including overcurrent, overvoltage, overtemperature, and short-circuit safeguards. The built-in STO SIL2 safety function further ensures that motors stop immediately under fault or emergency conditions, protecting both equipment and personnel.

Q: When should the overload protection capacities be considered during operation?

A: The MS300 series handles 150% of rated load for up to 60 seconds and 200% for up to 3 seconds. These capacities should be considered during applications where occasional load spikes are expected. Exceeding these limits consistently could trigger fault protection and potential shutdowns.

Q: Where can this inverter be installed, and what environments are most suitable?

A: The open-frame, panel-mount design is ideal for installation inside control panels in controlled indoor industrial environments. With a temperature tolerance from -10C to +50C and IP20 rating, its best suited for clean, dry locations typical in manufacturing facilities.

Q: What process does the VFD use to control motor speed and efficiency?

A: Utilizing both vector control and V/F control, the drive dynamically adjusts voltage and frequency to optimize motor speed and torque. Sensorless vector control allows for precise torque delivery without requiring a physical feedback sensor, enhancing efficiency and energy savings.

Q: What are the connectivity options available for automation integration?

A: The model features standard RS-485 (MODBUS) communication for direct PLC or SCADA connection. Optional communication interfaces such as CANopen, Profibus, and Ethernet can be added, allowing seamless integration with various automation systems.

Q: What advantages does the built-in EMC filter provide in industrial applications?

A: The EMC (Electromagnetic Compatibility) filter reduces electromagnetic interference, ensuring reliable operation of nearby sensitive electronic equipment. This built-in feature both simplifies installation and complies with industrial EMC standards, helping maintain signal integrity and operational safety.
